Product	Design	Total Length	Modul	Quality	Total Pitch Error	Helical Angle	Number of Bore Holes	Material	Gearing	Weight	Customs Tariff Number	Country of Origin
0002930104	Ultra High Precision Rack (UHPR)	1000 mm	3 mm	5	30 µm/m	19.52833	8	Heat-treatable steel acc. ATLANTA-Standard	ground (hardened)	5.64 kg	84839089	DE
0002950157	High Precision Rack (HPR)	1500 mm	5 mm	7	62 µm/m	19.52833	12	Heat-treatable steel acc. ATLANTA-Standard	ground (hardened)	19.50 kg	84839089	DE
0003981200	Basic Rack (BR)	1920 mm	8 mm	10	400 µm/m	19.52833	0	Heat-treatable steel acc. ATLANTA-Standard	milled (hardened)	85.00 kg	84839089	DE
0003981100	Basic Rack (BR)	960 mm	8 mm	10	200 µm/m	19.52833	0	Heat-treatable steel acc. ATLANTA-Standard	milled (hardened)	42.50 kg	84839089	DE
0003961200	Basic Rack (BR)	2000 mm	6 mm	10	400 µm/m	19.52833	0	Heat-treatable steel acc. ATLANTA-Standard	milled (hardened)	39.20 kg	84839089	DE
0003961100	Basic Rack (BR)	1000 mm	6 mm	10	200 µm/m	19.52833	0	Heat-treatable steel acc. ATLANTA-Standard	milled (hardened)	19.80 kg	84839089	DE
0003960200	Basic Rack (BR)	2000 mm	6 mm	10	400 µm/m	19.52833	16	Heat-treatable steel acc. ATLANTA-Standard	milled (hardened)	39.20 kg	84839089	DE
0003960100	Basic Rack (BR)	1000 mm	6 mm	10	200 µm/m	19.52833	8	Heat-treatable steel acc. ATLANTA-Standard	milled (hardened)	18.20 kg	84839089	DE
0003951100	Basic Rack (BR)	1000 mm	5 mm	10	200 µm/m	19.52833	0	Heat-treatable steel acc. ATLANTA-Standard	milled (hardened)	13.00 kg	84839089	DE
0003950200	Basic Rack (BR)	2000 mm	5 mm	10	400 µm/m	19.52833	16	Heat-treatable steel acc. ATLANTA-Standard	milled (hardened)	26.00 kg	84839089	DE
0003950100	Basic Rack (BR)	1000 mm	5 mm	10	200 µm/m	19.52833	8	Heat-treatable steel acc. ATLANTA-Standard	milled (hardened)	12.00 kg	84839089	DE
0003941200	Basic Rack (BR)	2000 mm	4 mm	10	400 µm/m	19.52833	0	Heat-treatable steel acc. ATLANTA-Standard	milled (hardened)	21.00 kg	84839089	DE
0003941100	Basic Rack (BR)	1000 mm	4 mm	10	200 µm/m	19.52833	0	Heat-treatable steel acc. ATLANTA-Standard	milled (hardened)	10.55 kg	84839089	DE
0003940200	Basic Rack (BR)	2000 mm	4 mm	10	400 µm/m	19.52833	16	Heat-treatable steel acc. ATLANTA-Standard	milled (hardened)	21.00 kg	84839089	DE
0003940100	Basic Rack (BR)	1000 mm	4 mm	10	200 µm/m	19.52833	8	Heat-treatable steel acc. ATLANTA-Standard	milled (hardened)	10.30 kg	84839089	DE
0003940050	Basic Rack (BR)	506.67 mm	4 mm	10	100 µm/m	19.52833	4	Heat-treatable steel acc. ATLANTA-Standard	milled (hardened)	5.32 kg	84839089	DE
